Infrared With Fujifilm FinePix 1300

I succeeded in modifying a Fujifilm FinePix 1300 to shoot in infrared. The camera is an ancient 1.3-megapixel model. I bought it used from the Palo Alto Goodwill for $6.99 plus tax, but since it was Sunday, all donated items were 30% off and I got it for just over five dollars.

It struck me as possible that the camera might have no high-pass filter at all, or at least an ineffective high-pass, which would mean than I could attach a low-pass filter to the objective side of the lens. This wouldn't be ideal, since filters tend to scatter light, and this scattering will of course degrade the image most severely if it occurs far from the CCD. However, attaching a filter to the objective side is a hell of a lot easier than attaching one to the CCD side. I held a weak low-pass filter in front of the lens, and took this shot:

Based upon the relative brightness of the sky and darkness of the foliage, I guessed that the FinePix still had some sort of high-pass filter, and although I wouldn't call it particularly effective, it was enough to ruin the IR sensitivity. My low-pass filters aren't terribly good either, so a low-pass on the objective side and a high-pass on the CCD side wouldn't give very good results.

I disassembled the camera and switched the filters. This took approximately six hours. In the process, I got a hell of a shock from the flash unit capacitor. However, since I had already spent four hours by that time, I was more concerned about the possibility that I might have acted as a conductor and discharged the flash unit into some sensitive electronics and destroyed the camera. Fortunately, when I re-assembled it, it worked well enough. The electromechanical components were extremely crude: the camera has two f/stop settings. There is a strip of metal with two holes in it which slides in front of one of the lens components. The larger hole corresponds to f/5.6, and I imagine the smaller hole is f/12 or so. To change f/stop, the strip of metal is simply moved about five millimeters by a solenoid.

When I reassembled the camera, I found it gave good IR images, and shot fairly deep into the IR. There is no true manual mode, but the camera does have an adjustable exposure setting, with settings ranging from +2 to -1.3 stops in increments of 0.3 [in layman's terms, if the default exposure is defined as X joules, and an exposure adjustment of +n is set, then the exposure is X * (2^n) joules]. This allows indirect control of shutter speed, and therefore makes infrared HDR (High Dynamic Range) imaging possible. The first images I shot were conventional. Click an image to see it larger.
+++
+++
"Charleston Road"

+++
"Space Heater"
This is a photograph of the elements in my space heater. The elements do not glow visibly when the heater is on, but they are hot enough to incandesce in the infrared. Similarly, electric burners will glow brightly in the infrared even when not hot enough to glow visibly. I spent several minutes photographing my stove in total darkness, but the pictures did not come out as well as this, and my housemate was rather confused. As he does not speak English, I had difficulty explaining myself.

+++
"House On Charleston Street"

+++
"Reflection In Vehicle"
This image shows the reflection of my vehicle in the side of a vehicle adjacent. Note that glass is highly opaque in infrared; this is to be expected. The interior of a car tends to become much hotter than the outside of the car on a sunny day precisely because glass is transparent to visible light but opaque to infrared: visible light enters the car through the windows, strikes the interior, and is converted to infrared, which cannot escape and builds up inside the vehicle, warming it. My driver's window was down.

+++
"Streets of San Mateo"
Note that all the glass in this image (the car windows, the building windows, and even the stoplights) appears jet black due to IR absorbance.

+++
"V4L"
The handsign "V" means "V4L" or "Volvo For Life". One can produce a full sequence of handsigns by holding up one's left hand and (in sequence) making a "V" with the pointer and middle finger, then holding up four fingers with the thumb folded back to indicate "4", and then making an "L" as described in the Smashmouth song: "She was lookin' kinda dumb with her finger and her thumb in the shape of an 'L' on her forehead...". Note that the shirt I was wearing in this image was black in the visible spectrum. Many fabrics that absorb visible light reflect infrared, and so appear white.

+++
+++
The following images were shot in high dynamic range; click to view larger:
+++
"Foliage On My Fence"

+++
"V4L-HDR-IR"

+++
"The CalTRAIN # 72"

+++
"This Picture Reminds Me Of The Song 'Dreaming Tree' And By Connection Reminds Me Of The Dave Matthews Phase I Went Through In High School"

+++
Peas out bros. I'm working on modifying another thrift-store camera (HP PhotoSmart 850, 4.1 megapixels, kickass lens) to shoot in IR.

Purple Haze

Purple Haze (though the color is variable depending on the white balance; I'm using 5900K)

+++

I recently tore apart my point-and-shoot camera (Canon Powershot a590), pulled out the high-pass filter, and installed a low-pass filter. The low-pass is opaque below approximately 800 nanometers (in the visible at least...I imagine it may not be UV-opaque but the glass takes care of that- as the saying goes, you can't get a tan through glass).

Unfortunately the low-pass I used tended to scatter the IR, and while adjusting it I destroyed the camera. Point-and-shoot cameras are not designed to be user-serviced, much less user-modified. Regardless, it was old, and today I am going to try the thrift store/craigslist circuit and look for something similar. Really, 3 megapixels is all I need, since the wavelength of IR is so damn long...no sense in having pixels if they're shorter than the wavelength you're shooting with.

Below are several photos I shot in IR. Really, I would like to shoot in UV, and I imagine that if I could make a set of lenses out of sapphire or fused quartz rather than glass I could get some UV sensitivity, but that's a fairly expensive proposition.

These images are not post-processed whatsoever. They have a purple cast; apparently the blue pixels on the point-and-shoot are the most sensitive to 800+ nm. light, even though they're not very sensitive to long-wave visible.

It is worthwhile to note that, even when the camera was functioning well enough for me to get these shots, there were some negative effects of switching the filters...besides severe blur, the switch caused the autofocus to fail and the lightmeter to become useless, since it is calibrated to visible light. The viewfinder still worked since it has an optical pathway separate from the objective lens, but since people can't see IR, the viewfinder isn't very useful because it doesn't show one what a given scene is likely to look like when photographed. In the case of a DSLR, one would have to use live view…in the case of a DSLR without live view, one would truly be shooting in the dark.

I think Erik would like IR photography. It is low-fi. If I find a few $20, four-year-old cameras and more than one survives my conversion attempts, I'll hook him up.

+++

Update: I managed to convert an old 1.3-megapixel Fujifilm camera to IR, and it gives very much better images than these. Unfortunately, I can’t get them off the camera since it uses a proprietary USB cable which I haven’t been able to find at any electronics stores. I’ll check some surplus places tomorrow; if worse comes to worse I’ll just buy a SmartMedia card reader.

+++

These images may be clicked and viewed larger.

+++
"Chairs My Housemate Uses To Dry Towels And Such"

+++
"Close Foliage"

+++
"Fence Shot At ISO 1600"

+++
"Shooting In Traffic"

+++
"Volvo For Life (V4L)"

+++
"West Charleston Street"

+++
Also, here are two photographs I didn't shoot but rather found in a place called "the internet". These are absolutely exemplary advertisements. The first is a professional shot; the second is a screen capture from New Moon which was altered by a fan. It demonstrates the kind of grass-roots, pro-vampire, pro-Volvo movement that America needs. The shop where I get my Volvo serviced has a gigantic poster of the professional print.
+++
